AM8061 Parts
Compare AM8061
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Rated torque | Rated speed | Rated power | Standstill current | Torque constant |
|---|---|---|---|---|---|
| AM8061-wNyz | 10.7 Nm | 5000 min-1 | 5.60 kW | 15.8 A | 0.97 Nm/A |
| AM8061-wLyz | 14.7 Nm | 3000 min-1 | 4.60 kW | 10.1 A | 1.64 Nm/A |
| AM8061-wHyz | 16.1 Nm | 1400 min-1 | 2.36 kW | 5.20 A | 3.30 Nm/A |
| AM8061-wMyz | 9.00 Nm | 5000 min-1 | 4.71 kW | 13.1 A | 0.97 Nm/A |
| AM8061-wJyz | 11.0 Nm | 3000 min-1 | 3.46 kW | 7.80 A | 1.64 Nm/A |
| AM8061-wGyz | 12.1 Nm | 1500 min-1 | 1.90 kW | 4.00 A | 3.20 Nm/A |
Common to all listed parts
| Motor type | permanent magnet-excited three-phase synchronous motor |
| Nominal voltage | 100…480 V AC |
| Peak torque | 37.1 Nm |
| Rotor moment of inertia | 11.1 kgcm² |
| Connection technology | M23 speedtec® plug |
| Ambient temperature (operation) | 5…40°C |
| Approvals/markings | CE, cURus |
| Design form | flange-mounted according to IM B5, IM V1, IM V3 |
