AM8033 Parts
Compare AM8033
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Rated torque | Peak torque | Rated speed | Rated power | Standstill current |
|---|---|---|---|---|---|
| AM8033-wJyz | 2.30 Nm | 17.22 Nm | 9000 min-1 | 2.17 kW | 6.80 A |
| AM8033-wFyz | 2.70 Nm | 17.71 Nm | 6000 min-1 | 1.70 kW | 4.10 A |
| AM8033-wEyz | 2.98 Nm | 17.19 Nm | 3000 min-1 | 0.94 kW | 2.10 A |
Common to all listed parts
| Motor type | permanent magnet-excited three-phase synchronous motor |
| Nominal voltage | 100…480 V AC |
| Rotor moment of inertia | 1.23 kgcm² |
| Cooling | convection |
| Connection technology | itec® plug |
| Ambient temperature (operation) | 5…40°C |
| Approvals/markings | CE, cURus |
| Protection rating | IP54, IP65 (shaft seal) |
