AMP8033 Parts
Compare AMP8033
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Standstill torque | Rated torque | Peak torque | Rated speed | Rated power |
|---|---|---|---|---|---|
| AMP8033-Ex1z | 3.15 Nm | 2.95 Nm | 17.2 Nm | 3000 min-1 | 0.93 kW |
| AMP8033-Ex2z | 3.15 Nm | 2.95 Nm | 17.2 Nm | 3000 min-1 | 0.93 kW |
| AMP8033-Ex3z | 3.15 Nm | 2.95 Nm | 17.2 Nm | 3000 min-1 | 0.93 kW |
| AMP8033-Ex4z | 3.15 Nm | 2.95 Nm | 17.2 Nm | 3000 min-1 | 0.93 kW |
| AMP8033-Fx1z | 3.15 Nm | 2.55 Nm | 14.36 Nm | 6000 min-1 | 1.60 kW |
| AMP8033-Fx2z | 3.15 Nm | 2.55 Nm | 14.36 Nm | 6000 min-1 | 1.60 kW |
| AMP8033-Fx3z | 3.15 Nm | 2.55 Nm | 14.36 Nm | 6000 min-1 | 1.60 kW |
| AMP8033-Fx4z | 3.15 Nm | 2.55 Nm | 14.36 Nm | 6000 min-1 | 1.60 kW |
| AMP8033-Jx1z | 3.10 Nm | 0.50 Nm | 9.37 Nm | 8000 min-1 | 0.42 kW |
| AMP8033-Jx2z | 3.10 Nm | 0.50 Nm | 9.37 Nm | 8000 min-1 | 0.42 kW |
| AMP8033-Jx3z | 3.10 Nm | 0.50 Nm | 9.37 Nm | 8000 min-1 | 0.42 kW |
| AMP8033-Jx4z | 3.10 Nm | 0.50 Nm | 9.37 Nm | 8000 min-1 | 0.42 kW |
Common to all listed parts
| DC link voltage | 0…848 V DC |
| Rotor moment of inertia | 1.23 kgcm² |
| System bus | EtherCAT |
| Drive profile | CiA402 according to IEC 61800-7-201 (CoE) |
| Connection technology | ECP B23 plug |
| Realization STO | by local TwinSAFE Logic or by FSoE |
| Ambient temperature (operation) | 5…40°C |
| Approvals/markings | CE, cULus, TÜV Süd |
