AMP8052 Parts
Compare AMP8052
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Standstill torque | Rated torque | Peak torque | Rated speed | Rated power |
|---|---|---|---|---|---|
| AMP8052-Fx1z | 7.60 Nm | 7.00 Nm | 35.3 Nm | 2000 min-1 | 1.47 kW |
| AMP8052-Fx2z | 7.60 Nm | 7.00 Nm | 35.3 Nm | 2000 min-1 | 1.47 kW |
| AMP8052-Fx3z | 7.60 Nm | 7.00 Nm | 35.3 Nm | 2000 min-1 | 1.47 kW |
| AMP8052-Fx4z | 7.60 Nm | 7.00 Nm | 35.3 Nm | 2000 min-1 | 1.47 kW |
| AMP8052-Jx1z | 7.60 Nm | 6.20 Nm | 23.4 Nm | 4000 min-1 | 2.60 kW |
| AMP8052-Jx2z | 7.60 Nm | 6.20 Nm | 23.4 Nm | 4000 min-1 | 2.60 kW |
| AMP8052-Jx3z | 7.60 Nm | 6.20 Nm | 23.4 Nm | 4000 min-1 | 2.60 kW |
| AMP8052-Jx4z | 7.60 Nm | 6.20 Nm | 23.4 Nm | 4000 min-1 | 2.60 kW |
| AMP8052-Lx1z | 5.60 Nm | 3.10 Nm | 14.2 Nm | 7300 min-1 | 2.37 kW |
| AMP8052-Lx2z | 5.60 Nm | 3.10 Nm | 14.2 Nm | 7300 min-1 | 2.37 kW |
| AMP8052-Lx3z | 5.60 Nm | 3.10 Nm | 14.2 Nm | 7300 min-1 | 2.37 kW |
| AMP8052-Lx4z | 5.60 Nm | 3.10 Nm | 14.2 Nm | 7300 min-1 | 2.37 kW |
Common to all listed parts
| DC link voltage | 0…848 V DC |
| Rotor moment of inertia | 4.08 kgcm² |
| System bus | EtherCAT |
| Drive profile | CiA402 according to IEC 61800-7-201 (CoE) |
| Connection technology | ECP B23 plug |
| Realization STO | by local TwinSAFE Logic or by FSoE |
| Ambient temperature (operation) | 5…40°C |
| Approvals/markings | CE, cULus, TÜV Süd |
