Motor cables Parts
Beckhoff
ZK4000-6877-0xxxMotor connection cable 0.75 mm² with M12 high-power plug (t coded), drag-chain suitable
Beckhoff
ZK4701-0421-2xxxMotor extension cable 0.75 mm² with itec® plug for motors with OCT, drag-chain suitable
Beckhoff
ZK4701-0461-2xxxMotor extension cable 0.75 mm² with itec® plug for motors with OCT, torsionable
Beckhoff
ZK4000-7700-0xxxMotor connection cable 0.75 mm² with M12 high-power plug (t coded), drag-chain suitable
Beckhoff
ZK4704-0401-2xxxMotor connection cable 0.75 mm² with itec® plug for motors with OCT, fixed installation
Beckhoff
ZK4704-0461-2xxxMotor connection cable 0.75 mm² with itec® plug for motors with OCT, torsionable
Beckhoff
ZK4704-0411-2xxxMotor connection cable 0.75 mm² with itec® plug for motors with resolver, drag-chain suitable
Beckhoff
ZK4000-7778-0xxxMotor connection cable 0.75 mm² with M12 high-power plug (t coded), drag-chain suitable
Compare Motor cables
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Installation size | Number of positions (face) | Cross-section (power) | Outer cable diameter | Max. number of cycles |
|---|---|---|---|---|---|
| ZK4500-8022-xxxx | Pitch dimension 3.50 mm | 5-pin | 1.00 mm² (approx. AWG18) | 11.6 mm ± 0.4 mm (0.4567" ± 0.0157") | 5 million |
| ZK4000-6200-2xxx | open end | 4-wire | 4 x 0.5 mm² (AWG20) | 5.35 ± 0.15 mm | 4 million |
| ZK4000-6768-0xxx | M12 | 4-pin | — | 6.0 mm ± 0.2 mm ("0.23622 ± 0.0079") | 4 million |
| ZK4000-5100-2xxx | open end | 5-wire + shielding | — | 5.65 mm ± 0.2 mm (0.2224" ± 0.0079") | 2 million |
| ZK4000-6261-0xxx | M12 | 4-pin | 4 x 0.5 mm² (AWG20) | 5.35 ± 0.15 mm | 4 million |
| ZK4000-6877-0xxx | M12 | 4-pin | 0.75 mm² (approx. AWG18) | 6.2 mm ± 0.2mm (0.244" ± 0.0079") | 2 million |
| ZK4701-0421-2xxx | itec® (Series 915) | Power: 3+PE, Signal: 5 | 0.75 mm² (approx. AWG18) | 11.0 mm ± 0.4 mm (0.433" ± 0.0157") | 5 million |
| ZK4000-6100-2xxx | open end | 4-wire | 4 x 0.5 mm² (AWG20) | 5.35 ± 0.15 mm | 4 million |
| ZK4701-0461-2xxx | itec® (Series 915) | Power: 3+PE, Signal: 5 | 0.75 mm² (approx. AWG18) | 12.0 mm ± 0.2 mm (0.472" ± 0.0079") | 5 million |
| ZK4000-6800-2xxx | open end | 4-wire + strand and shielding | — | 6.0 mm ± 0.2 mm ("0.23622 ± 0.0079") | 4 million |
| ZK4000-6700-2xxx | open end | 4-wire + strand and shielding | — | 6.0 mm ± 0.2 mm ("0.23622 ± 0.0079") | 4 million |
| ZK4054-6400-0xxx | open end | 3-wire | — | 6.0 mm ± 0.2 mm ("0.23622 ± 0.0079") | 4 million |
| ZK4000-7700-0xxx | open end | 4-wire + strand and shielding | 0.75 mm² (approx. AWG18) | 6.2 mm ± 0.2mm (0.244" ± 0.0079") | 2 million |
| ZK4704-0401-2xxx | open end | 8-wire + shield | 0.75 mm² (approx. AWG18) | 7.0 mm ± 0.3 mm (0.2756" ± 0.0118") | — |
| ZK4704-0461-2xxx | open end | 8-wire + shield | 0.75 mm² (approx. AWG18) | 12.0 mm ± 0.2 mm (0.472" ± 0.0079") | 5 million |
| ZK4704-0411-2xxx | open end | 6-wire + shielding | 0.75 mm² (approx. AWG18) | 8.8 mm ± 0.2 mm (0.3464" ± 0.0079") | 10 million |
| ZK4000-5151-0xxx | M12 | 5-pin | — | 5.65 mm ± 0.2 mm (0.2224" ± 0.0079") | 2 million |
| ZK4000-5152-0xxx | M12 | 5-pin | — | 5.65 mm ± 0.2 mm (0.2224" ± 0.0079") | 2 million |
| ZK4000-7778-0xxx | M12 | 4-pin | 0.75 mm² (approx. AWG18) | 6.2 mm ± 0.2mm (0.244" ± 0.0079") | 2 million |
| ZK4800-8022-0xxx | Pitch dimension 7.62 mm | 4-pin | 1.00 mm² (approx. AWG18) | 11.6 mm ± 0.4 mm (0.4567" ± 0.0157") | 5 million |
| ZK4800-8062-xxxx | Pitch dimension 7.62 mm | 4-pin | 1.00 mm² (approx. AWG18) | 12.0 mm ± 0.2 mm (0.472" ± 0.0079") | 2 million |
| ZK4800-8003-xxxx | Pitch dimension 7.62 mm | 4-pin | 1.50 mm² (approx. AWG16) | 12.2 mm ± 0,4 mm (0,4803" ± 0,0157") | — |
| ZK4800-8023-xxxx | Pitch dimension 7.62 mm | 4-pin | 1.50 mm² (approx. AWG16) | 12.7 mm ± 0.4 mm (0.5" ± 0.0157") | 5 million |
| ZK4800-8004-xxxx | Pitch dimension 7.62 mm | 4-pin | 2.50 mm² (approx. AWG14) | 13.8 mm ± 0,4 mm (0,5433" ± 0,0157") | — |
