Sensor cables Parts
Compare Sensor cables
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Number of positions (face) | Rated voltage | Outer cable diameter | A1 | A2 |
|---|---|---|---|---|---|
| ZK2000-7122-0xxx | 3-pin | 60 V (according to IEC 61076-2-104) | 5.4 mm ± 0.2 mm (0.213" ±0.0079") | 49.0 mm | Ø 14.5 mm |
| ZK2000-7132-0xxx | 4-pin | 30 V (according to IEC 61076-2-104) | 5.4 mm ± 0.2 mm (0.213" ±0.0079") | 49.0 mm | Ø 14.5 mm |
| ZK2000-7171-0xxx | 5-pin | 60 V (according to IEC 61076-2-101) | 5.4 mm ± 0.2 mm (0.213" ±0.0079") | 49.0 mm | Ø 14.5 mm |
| ZK2000-7172-0xxx | 5-pin | 60 V (according to IEC 61076-2-101) | 5.4 mm ± 0.2 mm (0.213" ±0.0079") | 49.0 mm | Ø 14.5 mm |
| ZK2000-7200-0xxx | 4-wire + strand and shielding | 60 V (according to IEC 61076-2-101) | 5.4 mm ± 0.2 mm (0.213" ±0.0079") | 44.0 mm | Ø 14.5 mm |
| ZK2000-7300-0xxx | 4-wire + strand and shielding | 60 V (according to IEC 61076-2-101) | 5.4 mm ± 0.2 mm (0.213" ±0.0079") | 35.00 mm | 32.00 mm |
| ZK2000-8100-0xxx | 8-wire | 30 V (according to IEC 61076-2-101) | 6.6 mm ± 0.2mm (0.259" ± 0.0079") | 49.00 mm | Ø14.50 mm |
| ZK2000-8172-0xxx | 5-pin | 60 V (according to IEC 61076-2-101) | 5.4 mm ± 0.2 mm (0.213" ±0.0079") | 49.00 mm | Ø14.50 mm |
| ZK2000-8182-0xxx | 8-pin | 30 V (according to IEC 61076-2-101) | 6.6 mm ± 0.2mm (0.259" ± 0.0079") | 49.00 mm | Ø14.50 mm |
| ZK2000-8200-0xxx | 8-wire | 30 V (according to IEC 61076-2-101) | 6.6 mm ± 0.2mm (0.259" ± 0.0079") | 44,0 mm | Ø14.50 mm |
| ZK2002-2122-0xxx | 3-pin | 60 V (according to IEC 61076-2-104) | 4.4 mm ± 0.15 mm (0.173" ± 0.0059") | 39.60 mm | Ø 10.1 mm |
| ZK2002-2124-0xxx | 3-pin | 60 V (according to IEC 61076-2-104) | 4.4 mm ± 0.15 mm (0.173" ± 0.0059") | 39.60 mm | Ø 10.1 mm |
| ZK2002-2200-0xxx | 3-wire | 60 V (according to IEC 61076-2-104) | 4.4 mm ± 0.15 mm (0.173" ± 0.0059") | 33.60 mm | — |
| ZK2002-2324-0xxx | 3-pin | 60 V (according to IEC 61076-2-104) | 4.4 mm ± 0.15 mm (0.173" ± 0.0059") | 27.50 mm | 26.30 mm |
| ZK2002-2400-0xxx | 3-wire | 60 V (according to IEC 61076-2-104) | 4.4 mm ± 0.15 mm (0.173" ± 0.0059") | 27.50 mm | 20.30 mm |
| ZK2002-3200-0xxx | 4-wire | 30 V (according to IEC 61076-2-104) | 4.4 mm ± 0.15 mm (0.173" ± 0.0059") | 34.00 mm | Ø 10.1 mm |
| ZK2002-3400-0xxx | 4-wire | 30 V (according to IEC 61076-2-104) | 4.4 mm ± 0.15 mm (0.173" ± 0.0059") | 27.50 mm | 19.20 mm |
| ZK2002-6162-0xxx | 4-pin | 250 V (according to IEC 61076-2-101) | 4.7 mm ± 0.15 mm (0.185" ± 0.0059") | 49.00 mm | 14.50 mm |
| ZK2002-6164-0xxx | 4-pin | 250 V (according to IEC 61076-2-101) | 4.7 mm ± 0.15 mm (0.185" ± 0.0059") | 49.00 mm | 14.50 mm |
| ZK2002-6200-0xxx | 4-wire | 250 V (according to IEC 61076-2-101) | 4.7 mm ± 0.15 mm (0.185" ± 0.0059") | 57.00 mm | 20.00 mm |
| ZK2002-6400-0xxx | 4-wire | 250 V (according to IEC 61076-2-101) | 4.7 mm ± 0.15 mm (0.185" ± 0.0059") | 35.00 mm | 26.80 mm |
| ZK4042-0100-0xxx | 3-wire | 32 V AC/DC | 4.60 mm ± 0.20 mm (0.181" ± 0.00787") | — | — |
| ZK2000-2124-0xxx | 3-pin | 60 V (according to IEC 61076-2-104) | 4.4 mm ± 0.15 mm (0.173" ± 0.0059") | 39.60 mm | Ø 10.1 mm |
| ZK2000-8100-3xxx | 8-wire + shield | 30 V (according to IEC 61076-2-101) | 6.6 mm ± 0.2mm (0.259" ± 0.0079") | 49.00 mm | Ø14.50 mm |
