Digital-Ausgang EPI2xxx Parts

Beckhoff EPI2008-0001 – IO-Link box, 8-channel digital output, 24 V DC, 0.5 A, M8

Beckhoff

IO-Link box, 8-channel digital output, 24 V DC, 0.5 A, M8

Beckhoff EPI2008-0002 – IO-Link box, 8-channel digital output, 24 V DC, 0.5 A, M12

Beckhoff

IO-Link box, 8-channel digital output, 24 V DC, 0.5 A, M12

Beckhoff EPI2809-0021 – IO-Link box, 16-channel digital output, 24 V DC, 0.5 A, M8

Beckhoff

IO-Link box, 16-channel digital output, 24 V DC, 0.5 A, M8

Beckhoff EPI2809-0022 – IO-Link box, 16-channel digital output, 24 V DC, 0.5 A, M12

Beckhoff

IO-Link box, 16-channel digital output, 24 V DC, 0.5 A, M12

Compare Digital-Ausgang EPI2xxx

Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.

MPN	Number of outputs	Output connections	Weight	Dimensions (W x H x D)
EPI2008-0001	8	M8, screw type	approx. 165 g	30 mm x 126 mm x 26.5 mm
EPI2008-0002	8	M12, screw type	approx. 165 g	30 mm x 126 mm x 26.5 mm
EPI2809-0021	16	M8, screw type	approx. 250 g	60 mm x 126 mm x 26.5 mm
EPI2809-0022	16	M12, screw type	approx. 250 g	60 mm x 126 mm x 26.5 mm

Common to all listed parts

Communication	IO-Link
Interfaces	1 x M12 plug, A-coded
Data transfer rates	230.4 kbaud (COM 3)
Specification version	IO-Link V1.1, Class B
Load type	ohmic, inductive, lamp load
Nominal output voltage	24 V DC (-15%/+20%)
Short-circuit current	typ. 1.5 A
Current consumption	typ. 100 mA from L+
