8LTSC (size C) Parts
Compare 8LTSC (size C)
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Nominal torque M n [Nm] | Nominal power P N [W] | Nominal current I N [A] | Stall current I 0 [A] | Maximum current I max [A] |
|---|---|---|---|---|---|
| 8LTSC3.ee003ffgg-0 | 176 | 5529 | 10.81 | 12 | 30.7 |
| 8LTSC3.ee005ffgg-0 | 163 | 8535 | 16.69 | 20.1 | 51.2 |
| 8LTSC3.eeA08ffgg-0 | 190 | 1592 | 3.89 | 4 | 10.2 |
| 8LTSC4.ee003ffgg-0 | 344 | 10807 | 21.13 | 23.5 | 62.6 |
| 8LTSC4.ee005ffgg-0 | 318 | 16650 | 32.55 | 39.2 | 104.3 |
| 8LTSC4.eeA08ffgg-0 | 372 | 3116 | 7.62 | 7.8 | 20.9 |
| 8LTSC5.ee003ffgg-0 | 498 | 15645 | 30.59 | 34 | 93.8 |
| 8LTSC5.ee005ffgg-0 | 461 | 24138 | 47.19 | 56.6 | 156.4 |
| 8LTSC5.eeA08ffgg-0 | 540 | 4524 | 11.06 | 11.3 | 31.3 |
| 8LTSC6.ee003ffgg-0 | 643 | 20200 | 39.49 | 43.9 | 125.1 |
| 8LTSC6.ee005ffgg-0 | 596 | 31206 | 61.01 | 73.1 | 208.44 |
| 8LTSC6.eeA08ffgg-0 | 695 | 5822 | 14.23 | 14.6 | 41.7 |
| 8LTSC7.ee003ffgg-0 | 780 | 24504 | 47.91 | 53.3 | 155.8 |
| 8LTSC7.eeA08ffgg-0 | 845 | 7079 | 17.3 | 17.8 | 51.9 |
| 8LTSC8.ee003ffgg-0 | 918 | 28840 | 56.38 | 62.6 | 187.6 |
| 8LTSC8.eeA08ffgg-0 | 993 | 8319 | 20.33 | 20.9 | 62.5 |
Common to all listed parts
| Number of pole pairs | 15 |
| Maximum speed n max [rpm] | 700 |
| Holding torque of brake M Br [Nm] | 0 |
| Mass of brake [kg] | 0 |
| Moment of inertia of brake J Br [kgcm 2] | 0 |
