Optional line chokes Parts

B&R

8I0CS004.000-1

Mains choke 1-phase 4 A Can be for ACOPOSinverter P66

B&R

8I0CS007.000-1

Mains choke 1-phase 7 A Can be for ACOPOSinverter P66

B&R

8I0CS018.000-1

Mains choke 1-phase 18 A Can be for ACOPOSinverter P66

B&R

8I0CT004.000-1

Mains choke 3-phase, 4 A, 50/60 for ACOPOSinverter

B&R

8I0CT010.000-1

Mains choke 3-phase, 10 A, 50/60 Hz for ACOPOSinverter

B&R

8I0CT016.000-1

Mains choke 3-phase, 17 A, 50/60 Hz for ACOPOSinverter

B&R

8I0CT030.000-1

Mains choke 3-phase, 30 A, 50/60 Hz for ACOPOSinverter

B&R

8I0CT001.570-1

ACPi mains choke 3-ph 1.5 A

B&R

8I0CT002.570-1

ACPi mains choke 3-ph 2 A

B&R

8I0CT030.570-1

ACPi mains choke 3-ph 30 A

B&R

8I0CT008.570-1

ACPi mains choke 3-ph 8 A

B&R

8I0CT010.570-1

ACPi mains choke 3-ph 10 A

B&R

8I0CS005.570-1

ACPi mains choke 1-ph 5 A

B&R

8I0CT006.570-1

ACPi mains choke 3-ph 6 A

B&R

8I0CT016.570-1

ACPi mains choke 3-ph 16 A

B&R

8I0CT004.570-1

ACPi mains choke 3-ph 4 A

B&R

8I0CS009.570-1

ACPi mains choke 1-ph 9 A

B&R

8I0CS018.570-1

ACPi mains choke 1-ph 18 A

Compare Optional line chokes

Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.

MPN	Power dissipation	Inductance	Degree of protection – Terminals	Weight
8I0CS004.000-1	17 W	10 mH	IP20	0.63 kg
8I0CS007.000-1	20 W	5 mH	IP20	0.88 kg
8I0CS018.000-1	30 W	2 mH	IP20	1.99 kg
8I0CT004.000-1	45 W	10 mH	IP20	1.5 kg
8I0CT010.000-1	65 W	4 mH	IP20	3.0 kg
8I0CT016.000-1	75 W	2 mH	IP20	3.5 kg
8I0CT030.000-1	90 W	1 mH	IP10	6.0 kg

Common to all listed parts

Certifications – CE	Yes
Certifications – UKCA	Yes
Certifications – KC	Yes
Degree of protection – Choke	IP00
Installation elevation above sea level	0 to 1000 m
Max. relative humidity	95%, non-condensing ; No dripping water
Ambient temperature	0 to 45°C
Max. ambient temperature	Up to 55°C (note: With current reduction of 2% per °C above 45°C.)
