8LTQ9 (size 9) Parts
Compare 8LTQ9 (size 9)
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Nominal torque M n [Nm] | Nominal current I N [A] | Stall current I 0 [A] | Maximum current I max [A] | Stator resistance R 2ph [Ω] |
|---|---|---|---|---|---|
| 8LTQ93.ee003ffgg-0 | 48 | 2.9 | 3 | 18.2 | 10.88 |
| 8LTQ93.ee005ffgg-0 | 45 | 4.5 | 5 | 30.4 | 3.718 |
| 8LTQ93.ee010ffgg-0 | 39 | 8.2 | 10.5 | 64.1 | 0.82 |
| 8LTQ94.ee003ffgg-0 | 95 | 5.7 | 6 | 34 | 4.253 |
| 8LTQ94.ee005ffgg-0 | 90 | 9.1 | 10.1 | 57.3 | 1.628 |
| 8LTQ94.ee010ffgg-0 | 77 | 15.9 | 20.6 | 116.6 | 0.403 |
| 8LTQ95.ee003ffgg-0 | 142 | 8.5 | 8.9 | 48.9 | 2.815 |
| 8LTQ95.ee005ffgg-0 | 135 | 13.7 | 15.2 | 83.2 | 0.962 |
| 8LTQ95.ee010ffgg-0 | 116 | 23.5 | 30.4 | 166.2 | 0.24 |
| 8LTQ96.ee003ffgg-0 | 188 | 11.2 | 11.9 | 65.1 | 1.972 |
| 8LTQ96.ee005ffgg-0 | 180 | 17.9 | 19.9 | 108.9 | 0.725 |
| 8LTQ96.ee010ffgg-0 | 153 | 31 | 40.5 | 221.6 | 0.171 |
| 8LTQ97.ee003ffgg-0 | 225 | 13.4 | 14.3 | 78.2 | 1.765 |
| 8LTQ97.ee005ffgg-0 | 212 | 21.1 | 23.9 | 130.7 | 0.598 |
| 8LTQ97.ee010ffgg-0 | 182 | 36.9 | 48.6 | 265.9 | 0.146 |
Common to all listed parts
| Number of pole pairs | 12 |
| Maximum speed n max [rpm] | 1200 |
| Holding torque of brake M Br [Nm] | 0 |
| Mass of brake [kg] | 0 |
| Moment of inertia of brake J Br [kgcm 2] | 0 |
