1494G Heavy Industrial Safety Disconnect Switches Parts
Compare 1494G Heavy Industrial Safety Disconnect Switches
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Switch Ampere Rating | Disconnect Type | Fuse Clips | Fuse Voltage | Enclosure Size [length x width x depth] |
|---|---|---|---|---|---|
| 1494G-DF3N-98-412 | 100A | Non-Fusible | Non-Fusible | Non-fusible | 20 x 10 x 9 in. |
| 1494G-DF3N-98-203W-423 | 100A | Non-Fusible | Non-Fusible | Non-fusible | 20 x 10 x 9 in. |
| 1494G-DF3N-98-203W-414 | 100A | Non-Fusible | Non-Fusible | Non-fusible | 20 x 10 x 9 in. |
| 1494G-CF3R6 | 60A | Fusible | Class R fuse clips | 600VAC | 20 x 10 x 9 in. |
| 1494G-CF3R2-98 | 60A | Fusible | Class R fuse clips | 240VAC | 13 x 10 x 8 in. |
| 1494G-CF3R2 | 60A | Fusible | Class R fuse clips | 240VAC | 13 x 10 x 8 in. |
| 1494G-CF3N-98-414 | 60A | Non-Fusible | Non-Fusible | Non-fusible | 13 x 10 x 8 in. |
| 1494G-CF3N-98-412-414 | 60A | Non-Fusible | Non-Fusible | Non-fusible | 13 x 10 x 8 in. |
| 1494G-CF3N-98-412 | 60A | Non-Fusible | Non-Fusible | Non-fusible | 13 x 10 x 8 in. |
| 1494G-CF3N-98 | 60A | Non-Fusible | Non-Fusible | Non-fusible | 13 x 10 x 8 in. |
| 1494G-CF3N-412-989 | 60A | Non-Fusible | Non-Fusible | Non-fusible | 13 x 10 x 8 in. |
| 1494G-CF3N-412-414 | 60A | Non-Fusible | Non-Fusible | Non-fusible | 13 x 10 x 8 in. |
| 1494G-CF3N-3S-98-203W | 60A | Non-Fusible | Non-Fusible | Non-fusible | 13 x 10 x 8 in. |
| 1494G-CF3N-3S-98 | 60A | Non-Fusible | Non-Fusible | Non-fusible | 13 x 10 x 8 in. |
| 1494G-CF3N-3EI-203W-989 | 60A | Non-Fusible | Non-Fusible | Non-fusible | 13 x 10 x 8 in. |
| 1494G-CF3N-3E-989 | 60A | Non-Fusible | Non-Fusible | Non-fusible | 13 x 10 x 8 in. |
| 1494G-CF3N-3E-98 | 60A | Non-Fusible | Non-Fusible | Non-fusible | 13 x 10 x 8 in. |
| 1494G-CF3N-3E-203W-989 | 60A | Non-Fusible | Non-Fusible | Non-fusible | 13 x 10 x 8 in. |
| 1494G-CF3N-3 | 60A | Non-Fusible | Non-Fusible | Non-fusible | 13 x 10 x 8 in. |
| 1494G-CF3N-203W-988 | 60A | Non-Fusible | Non-Fusible | Non-fusible | 13 x 10 x 8 in. |
| 1494G-CF3N-1SB | 60A | Non-Fusible | Non-Fusible | Non-fusible | 13 x 10 x 8 in. |
| 1494G-CF3N-1S-98-412 | 60A | Non-Fusible | Non-Fusible | Non-fusible | 13 x 10 x 8 in. |
| 1494G-CF3N-1S-98-203W | 60A | Non-Fusible | Non-Fusible | Non-fusible | 13 x 10 x 8 in. |
| 1494G-CF3J6-99 | 60A | Fusible | Class J fuse clips | 600VAC | 13 x 10 x 8 in. |
Common to all listed parts
| Current Product Selection Availability (may change based on options selected below) | Catalog is configured at order entry |
| Phases | Three Phase |
| Enclosure Code | Type 3R/4/12 - Enclosure Code F |
| Pole Configuration | 3 pole, three phase |
