Mitsubishi Low-voltage switchgear – Magnetic Starters Parts
























Compare Mitsubishi Low-voltage switchgear – Magnetic Starters
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V | Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V | Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V | Main Contact Making Current Capacity [A]: Category AC-3: AC220V |
|---|---|---|---|---|---|
| MSO-N21SR | 4 | 7.5 | 18 | 18 | 220 |
| MSO-N20SR | 4 | 7.5 | 18 | 18 | 220 |
| MSO-N12SR | 2.7 | 4 | 13 | 9 | 130 |
| MSO-N11SR | 2.7 | 4 | 13 | 9 | 130 |
| MSO-N10SR | 2.2 | 2.7 | 11 | 7 | 110 |
| MSO-N95FS | 22 | 45 | 93 | 93 | 1050 |
| MSO-N80FS | 19 | 37 | 80 | 80 | 850 |
| MSO-N65FS | 15 | 30 | 65 | 65 | 650 |
| MSO-N50FS | 11 | 22 | 50 | 48 | 550 |
| MSO-N35FS | 7.5 | 15 | 34 | 32 | 400 |
| MSO-N25FS | 5.5 | 11 | 26 | 25 | 300 |
| MSO-N21FS | 4 | 7.5 | 18 | 18 | 220 |
| MSO-N20FS | 4 | 7.5 | 18 | 18 | 220 |
| MSO-N95KF | 22 | 45 | 93 | 93 | 1050 |
| MSO-N80KF | 19 | 37 | 80 | 80 | 850 |
| MSO-N65KF | 15 | 30 | 65 | 65 | 650 |
| MSO-N50KF | 11 | 22 | 50 | 48 | 550 |
| MSO-N35KF | 7.5 | 15 | 34 | 32 | 400 |
| MSO-N25KF | 5.5 | 11 | 26 | 25 | 300 |
| MSO-N21KF | 4 | 7.5 | 18 | 18 | 220 |
| MSO-N20KF | 4 | 7.5 | 18 | 18 | 220 |
| MSO-N12KF | 2.7 | 4 | 13 | 9 | 130 |
| MSO-N11KF | 2.7 | 4 | 13 | 9 | 130 |
| MSO-N10KF | 2.2 | 2.7 | 11 | 7 | 110 |
Common to all listed parts
| Series | Low-voltage switchgear |
| Rated Insulation Voltage Ui [V] | 690 |
| Main Contact Minimal Applicable Load | 48V 200mA |
| Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC120V | 6 |
| Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V | 3 |
| Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC440V | 1.5 |
| Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC550V | 1.2 |
| Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC120V | 10 |
