Mitsubishi Low-voltage switchgear – Magnetic Starters Parts
























Compare Mitsubishi Low-voltage switchgear – Magnetic Starters
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC220 to 240V | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC380 to 440V | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC500V |
|---|---|---|---|---|---|
| MSOLD-N80KP | 19 | 37 | 22 | 45 | 45 |
| MSOLD-N65KP | 15 | 30 | 18.5 | 30 | 37 |
| MSOLD-N50KP | 11 | 22 | 15 | 22 | 25 |
| MSOLD-N35KP | 7.5 | 15 | 11 | 18.5 | 18.5 |
| MSOLD-N21KP | 4 | 7.5 | 5.5 | 11 | 11 |
| MSOLD-N400 | 110 | 200 | 125 | 220 | 225 |
| MSOLD-N300 | 75 | 150 | 90 | 160 | 160 |
| MSOLD-N220 | 55 | 110 | 75 | 132 | 132 |
| MSOLD-N150 | 37 | 75 | 45 | 75 | 90 |
| MSOLD-N125 | 30 | 60 | 37 | 60 | 60 |
| MSOLD-N95 | 22 | 45 | 30 | 55 | 55 |
| MSOLD-N80 | 19 | 37 | 22 | 45 | 45 |
| MSOLD-N65 | 15 | 30 | 18.5 | 30 | 37 |
| MSOLD-N50 | 11 | 22 | 15 | 22 | 25 |
| MSOLD-N35 | 7.5 | 15 | 11 | 18.5 | 18.5 |
| MSOLD-N21 | 4 | 7.5 | 5.5 | 11 | 11 |
| MSOL-N35CXKP | 7.5 | 15 | 11 | 18.5 | 18.5 |
| MSOL-N21CXKP | 4 | 7.5 | 5.5 | 11 | 11 |
| MSOL-N35CX | 7.5 | 15 | 11 | 18.5 | 18.5 |
| MSOL-N21CX | 4 | 7.5 | 5.5 | 11 | 11 |
| MSOL-N400KP | 110 | 200 | 125 | 220 | 225 |
| MSOL-N300KP | 75 | 150 | 90 | 160 | 160 |
| MSOL-N220KP | 55 | 110 | 75 | 132 | 132 |
| MSOL-N150KP | 37 | 75 | 45 | 75 | 90 |
Common to all listed parts
| Series | Low-voltage switchgear |
| Product Specification | Mechanically Latched Type |
| Main Contact Minimal Applicable Load | 48V 200mA |
| Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC120V | 6 |
| Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V | 3 |
| Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC440V | 1.5 |
| Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC550V | 1.2 |
| Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC120V | 10 |
