800FD Monolithic Push Buttons Parts
Compare 800FD Monolithic Push Buttons
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Lifecycle | Contact block configuration | Operator cap color (lens) | Operator cap text/symbol | Number of contacts as normally closed contact |
|---|---|---|---|---|---|
| 800FD-F4R10 | Active | 1 NO | Red | Blank | — |
| 800FD-F4R02 | Discontinued | 2 NC | Red | Blank | 2 |
| 800FD-F301R01 | Discontinued | 1 NC | Green | START | 1 |
| 800FD-F405R01 | Discontinued | 1 NC | Red | O | 1 |
| 800FD-F3R20 | Discontinued | 2 NO | Green | Blank | — |
| 800FD-F4R11 | Discontinued | 1 NO/1 NC | Red | Blank | 1 |
Common to all listed parts
| Repair options available | No |
| Type | 22mm Momentary Push Button |
| Contact block durability | 300000 |
| Contact block mounting style | Latch |
| Contact block operational voltage, max | 300V AC @ 300V DC (B300, R300) - screw for ring lug termination |
| Contact block termination tightening torque | 6 - 8 in-lb / 0.7 - 0.9 N-m |
| Contact block termination wire range | #18...12 AWG (0.75...2.5 mm²) |
| Contact block thermal current rating | 5 A |
