800FC Pendant Stations Parts

Showing 25–48 of 362 parts
Allen-Bradley 800FP-MT34PX01V – 22mm Twist To Release E-Stop 800F PB
Allen-Bradley
800FP-MT34PX01V

22mm Twist To Release E-Stop 800F PB

Allen-Bradley 800FP-MP44PQ02 – 22mm Push Pull Operator 800F PB
Allen-Bradley
800FP-MP44PQ02

22mm Push Pull Operator 800F PB

Allen-Bradley 800FP-MT44PX32 – 22mm Twist To Release E-Stop 800F PB
Allen-Bradley
800FP-MT44PX32

22mm Twist To Release E-Stop 800F PB

Allen-Bradley 800FP-GX – 22mm Momentary Push Button 800F PB
Allen-Bradley
800FP-GX

22mm Momentary Push Button 800F PB

Allen-Bradley 800FP-E3-BP – 22mm Momentary Push Button 800F PB
Allen-Bradley
800FP-E3-BP

22mm Momentary Push Button 800F PB

Allen-Bradley 800FP-E111 – 22mm Momentary Push Button 800F PB
Allen-Bradley
800FP-E111

22mm Momentary Push Button 800F PB

Allen-Bradley 800FP-CC2U296 – 22mm Momentary Push Button 800F PB
Allen-Bradley
800FP-CC2U296

22mm Momentary Push Button 800F PB

Allen-Bradley 800FP-E9-BP – 22mm Momentary Push Button 800F PB
Allen-Bradley
800FP-E9-BP

22mm Momentary Push Button 800F PB

Allen-Bradley 800FP-U2E4E2 – 22mm Multi-Operator 800F PB
Allen-Bradley
800FP-U2E4E2

22mm Multi-Operator 800F PB

Allen-Bradley 800FP-U2F4E3 – 22mm Multi-Operator 800F PB
Allen-Bradley
800FP-U2F4E3

22mm Multi-Operator 800F PB

Allen-Bradley 800FP-SM32PX60 – 22mm Selector Switch 800F PB
Allen-Bradley
800FP-SM32PX60

22mm Selector Switch 800F PB

Allen-Bradley 800FP-SM22PX60 – 22mm Selector Switch 800F PB
Allen-Bradley
800FP-SM22PX60

22mm Selector Switch 800F PB

Allen-Bradley 800FP-P6PN5W – 22mm Pilot Light 800F PB
Allen-Bradley
800FP-P6PN5W

/ – 22mm Pilot Light 800F PB

Allen-Bradley 800FP-SM32PX20 – 22mm Selector Switch 800F PB
Allen-Bradley
800FP-SM32PX20

/ – 22mm Selector Switch 800F PB

Compare 800FC Pendant Stations

Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.

MPNContact block configurationContact block utilization category (AC)Contact block utilization category (DC)Operator functionOperator type
800FP-MT34PX01V1 NCC300, AC 15 - low voltage contact blockR150, DC 13 - low voltage contact block22 mm twist to release E-stop30 mm twist to release
800FP-MP44MX02L2 NCA600, AC 15 - screw terminationQ600, DC-13 - screw termination22 mm push pull operator40 mm push-pull
800FP-LSM20PN3WX202 NOA600, AC 15 - screw terminationQ600, DC-13 - screw terminationMaintained, 2 positionIlluminated selector switch
800FP-MP44PQ022 NCA300, AC 15 - spring clA terminationQ300, DC-13 - spring clA termination22 mm push pull operator40 mm push-pull
800FP-LMM43PN3GX101 NOA600, AC 15 - screw terminationQ600, DC-13 - screw termination22 mm momentary push buttonPush button
800FP-LSM20PN7WX111 NO/1 NCA600, AC 15 - screw terminationQ600, DC-13 - screw terminationMaintained, 2 positionIlluminated selector switch
800FP-LSM20PN3WX111 NO/1 NCA600, AC 15 - screw terminationQ600, DC-13 - screw terminationMaintained, 2 positionIlluminated selector switch
800FP-LMP34PQ3RQ022 NCA300, AC 15 - spring clA terminationQ300, DC-13 - spring clA termination22 mm push pull operator30 mm illuminated push-pull
800FP-MT44PX323 NO/2 NCA600, AC 15 - screw terminationQ600, DC-13 - screw termination22 mm twist to release E-stop40 mm twist to release
800FP-GX———22 mm momentary push buttonPush button
800FP-E3-BP———22 mm momentary push buttonPush button
800FP-E111———22 mm momentary push buttonPush button
800FP-E9-BP———22 mm momentary push buttonPush button
800FP-U2E4E2———2 position multi-operatorPush button
800FP-U2F4E3———2 position multi-operatorPush button
800FP-SM32PX606 NOA600, AC 15 - Screw TerminationQ600, DC-13 - Screw TerminationMaintained, 3 positionSelector switch - standard knob
800FP-LSM23MN5GX202 NOA600, AC 15 - screw terminationQ600, DC-13 - screw terminationMaintained, 2 positionIlluminated selector switch
800FP-LSB36PN7WX202 NOA600, AC 15 - screw terminationQ600, DC-13 - screw terminationSpring return from both, 3 positionIlluminated selector switch
800FP-SM22PX606 NOA600, AC 15 - Screw TerminationQ600, DC-13 - Screw TerminationMaintained, 2 positionSelector switch - standard knob
800FP-SM22PX20V2 NOC300, AC 15 - Low Voltage Contact BlockR150, DC 13 - Low Voltage Contact BlockMaintained, 2 positionSelector switch - standard knob

Common to all listed parts

LifecycleActive
Repair options availableNo
Hole diameter22.5 mm
Humidity≤95% RH from 25...60 °C (77...140 °F)
Operating temperature-25 °C
Operator construction/materialPlastic
Storage temperature-40 °C
