Back of Panel Components, 30 mm Parts
Compare Back of Panel Components, 30 mm
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Operator cam code | Operator cap color | Operator function | Position 1 contact block | Position 2 contact block |
|---|---|---|---|---|---|
| 800T-26JW2KB7AG | KB7 | White | Maintained | 1-NO 1-NC standard contacts | 1-NOEM standard contact |
| 800T-26JR91KB7AA | KB7 | Red | Spring return from left and right | 1-NO 1-NC standard contacts | 1-NO 1-NC standard contacts |
| 800T-26JR2KE7AA | KE7 | Red | Maintained | 1-NO 1-NC standard contacts | 1-NO 1-NC standard contacts |
| 800T-24JG5KB7CA | KB7 | Green | Spring return from right | 1-NCLB 1-NC standard contacts | 1-NO 1-NC standard contacts |
| 800T-24JG5KB7AA | KB7 | Green | Spring return from right | 1-NO 1-NC standard contacts | 1-NO 1-NC standard contacts |
| 800T-24JG5KC1 | KC1 | Green | Spring return from right | — | — |
| 800T-26JR2KB7CC | KB7 | Red | Maintained | 1-NCLB 1-NC standard contacts | 1-NCLB 1-NC standard contacts |
| 800T-26HG2KB6AJ | KB6 | Green | Maintained | 1-NO 1-NC standard contacts | 1-NCLB standard contact |
| 800T-24JG2KC7JX | KC7 | Green | Maintained | 1-NCLB standard contact | No block this position |
| 800T-24JG2KC7AX | KC7 | Green | Maintained | 1-NO 1-NC standard contacts | No block this position |
| 800T-24JG2KC1BB | KC1 | Green | Maintained | 1-NCLB 1-NO standard contacts | 1-NCLB 1-NO standard contacts |
| 800T-26HG2KB6AM | KB6 | Green | Maintained | 1-NO 1-NC standard contacts | 2-NO standard contacts |
| 800T-26HG19KL8DX | KL8 | Green | Spring return from right | 1-NO standard contact | No block this position |
| 800T-26HG17KB6AX | KB6 | Green | Maintained | 1-NO 1-NC standard contacts | No block this position |
| 800T-26HG17KB6DX | KB6 | Green | Maintained | 1-NO standard contact | No block this position |
| 800T-26HG17KB6AA | KB6 | Green | Maintained | 1-NO 1-NC standard contacts | 1-NO 1-NC standard contacts |
| 800T-26HC2KB6DX | KB6 | Clear | Maintained | 1-NO standard contact | No block this position |
| 800T-26HC2KB6AX | KB6 | Clear | Maintained | 1-NO 1-NC standard contacts | No block this position |
| 800T-26HB17KB6AX | KB6 | Blue | Maintained | 1-NO 1-NC standard contacts | No block this position |
Common to all listed parts
| Lifecycle | Discontinued |
| Discontinued date | April 30, 2025 |
| Replacement category (Rockwell) | Direct Replacement |
| Repair options available | No |
| Enclosure compatibility (NEMA type) | 1, 4, 12, 13 |
| Hole diameter | 30.5 mm |
| Humidity | 50 % |
| Illumination lamp type | Incandescent |
