Home / Push Buttons & Signaling Devices / Back of Panel Components, 30 mm

Back of Panel Components, 30 mm Parts

Allen-Bradley

800T-E1544M6A4

30 mm Cyl Lock Push-Button 800T PB

Allen-Bradley

800T-E1544M6A1

30 mm Cyl Lock Push-Button 800T PB

Allen-Bradley

800T-E1544J6A1

30 mm Cyl Lock Push-Button 800T PB

Allen-Bradley

800T-E1544J6D1

30 mm Cyl Lock Push-Button 800T PB

Allen-Bradley

800T-D2FD2

30mm Momentary Push Button 800T PB

Allen-Bradley

800T-E1544J6

30 mm Cyl Lock Push-Button 800T PB

Allen-Bradley

800T-D2FB

30mm Momentary Push Button 800T PB

Allen-Bradley

800T-D2D6

30mm Momentary Push Button 800T PB

Allen-Bradley

800T-E15C

30 mm Cyl Lock Push-Button 800T PB

Allen-Bradley

800T-E15A2

30 mm Cyl Lock Push-Button 800T PB

Allen-Bradley

800T-E1568M6

30 mm Cyl Lock Push-Button 800T PB

Allen-Bradley

800T-E1569M6D4

30 mm Cyl Lock Push-Button 800T PB

Allen-Bradley

800T-E1566M6D4

30 mm Cyl Lock Push-Button 800T PB

Allen-Bradley

800T-E1567M6

30 mm Cyl Lock Push-Button 800T PB

Allen-Bradley

800T-E1567M6D4

30 mm Cyl Lock Push-Button 800T PB

Allen-Bradley

800T-E2438M6D4

30 mm Cyl Lock Push-Button 800T PB

Allen-Bradley

800T-E2437M6D2

30 mm Cyl Lock Push-Button 800T PB

Allen-Bradley

800T-E2438M6B

30 mm Cyl Lock Push-Button 800T PB

Allen-Bradley

800T-E2436M6D4

30 mm Cyl Lock Push-Button 800T PB

Allen-Bradley

800T-E2436M6D2

30 mm Cyl Lock Push-Button 800T PB

Allen-Bradley

800T-E2435M6D1

30 mm Cyl Lock Push-Button 800T PB

Allen-Bradley

800T-E2435M6B

30 mm Cyl Lock Push-Button 800T PB

Allen-Bradley

800T-E2435J6

30 mm Cyl Lock Push-Button 800T PB

Allen-Bradley

800T-E2435M6

30 mm Cyl Lock Push-Button 800T PB

Compare Back of Panel Components, 30 mm

Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.

MPN	Operator cap/button size	Operator cap color	Operator cap type	Operator lock key code	Operator special function
800T-E1544M6A4	40 mm	Red	Mushroom head	Spring bolt key E109	Dead Bolt A, Locking Position: Both
800T-E1544M6A1	40 mm	Red	Mushroom head	Spring bolt key E109	Dead Bolt A, Locking Position: Both
800T-E1544J6A1	60 mm	Red	Jumbo mushroom head	Spring bolt key E109	Dead Bolt A, Locking Position: Both
800T-E1544J6D1	60 mm	Red	Jumbo mushroom head	Spring bolt key E109	Dead Bolt A, Locking Position: Both
800T-D2FD2	40 mm	Black	Mushroom head	—	Padlocking, attachment NOT included
800T-E1544J6	60 mm	Red	Jumbo mushroom head	Spring bolt key E109	Dead Bolt A, Locking Position: Both
800T-D2FB	40 mm	Black	Mushroom head	—	Padlocking, attachment NOT included
800T-D2D6	40 mm	Black	Mushroom head	—	N/A
800T-E15C	N/A	N/A	Standard unit	E158 (standard key)	Dead Bolt A, Locking Position: Both
800T-E15A2	N/A	N/A	Standard unit	E158 (standard key)	Dead Bolt A, Locking Position: Both
800T-E1568M6	40 mm	Red	Mushroom head	Spring bolt key E117	Dead Bolt A, Locking Position: Both
800T-E1569M6D4	40 mm	Red	Mushroom head	Spring bolt key E125	Dead Bolt A, Locking Position: Both
800T-E1566M6D4	40 mm	Red	Mushroom head	Spring bolt key E106	Dead Bolt A, Locking Position: Both
800T-E1567M6	40 mm	Red	Mushroom head	Spring bolt key E111	Dead Bolt A, Locking Position: Both
800T-E1567M6D4	40 mm	Red	Mushroom head	Spring bolt key E111	Dead Bolt A, Locking Position: Both
800T-E2438M6D4	40 mm	Red	Mushroom head	Dead bolt A key E108	Dead Bolt A, Locking Position: Out
800T-E2437M6D2	40 mm	Red	Mushroom head	Dead bolt A key E104	Dead Bolt A, Locking Position: Out
800T-E2438M6B	40 mm	Red	Mushroom head	Dead bolt A key E108	Dead Bolt A, Locking Position: Out
800T-E2436M6D4	40 mm	Red	Mushroom head	Dead bolt A key E120	Dead Bolt A, Locking Position: Out
800T-E2436M6D2	40 mm	Red	Mushroom head	Dead bolt A key E120	Dead Bolt A, Locking Position: Out
800T-E2435M6D1	40 mm	Red	Mushroom head	Dead bolt A key E115	Dead Bolt A, Locking Position: Out
800T-E2435M6B	40 mm	Red	Mushroom head	Dead bolt A key E115	Dead Bolt A, Locking Position: Out
800T-E2435J6	60 mm	Red	Jumbo mushroom head	Dead bolt A key E115	Dead Bolt A, Locking Position: Out
800T-E2435M6	40 mm	Red	Mushroom head	Dead bolt A key E115	Dead Bolt A, Locking Position: Out

Common to all listed parts

Lifecycle	Discontinued
Discontinued date	April 30, 2025
Repair options available	No
Enclosure compatibility (NEMA type)	1, 4, 12, 13
Hazardous location rating	false
Hole diameter	30.5 mm
Humidity	50 %
Operating temperature	-25 °C
