Twido Parts




Twido connecting cable with IP6770 - way connector - 1.5 m for extreme base


















TwidoSuite V2.0 multi-language software - configuration programming - DVD-ROM


Analog I/O module Twido - 24 V DC supply - 4 inputs and 2 ouputs 0-10V, 4-20 mA
Compare Twido
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Net weight | Product or component type | I/O connection | Insulation between channel and internal logic | Product certifications |
|---|---|---|---|---|---|
| TWDFTB2T10 | — | — | — | — | — |
| TWDFTB2T13 | — | — | — | — | — |
| TWDFTB2T11 | — | — | — | — | — |
| TWDFCWK70L015 | 2.92 kg | — | — | — | — |
| TWDFCW50M | 0.67 kg | — | — | — | — |
| TWDFCW30M | 0.405 kg | — | — | — | — |
| TWDFCNK70 | 0.2 kg | — | — | — | — |
| TWDDRA8RT | 0.11 kg | Discrete output module | Removable screw terminal block | 1500 Vrms for 1 minute | UL; CSA |
| TWDDRA16RT | 0.145 kg | Discrete output module | Removable screw terminal block | 1500 Vrms for 1 minute | CSA; UL |
| TWDDMM8DRT | 0.095 kg | Discrete I/O module | Removable screw terminal block | 1500 Vrms for 1 min (by photocoupler) | CSA; UL |
| TWDDMM24DRF | 0.14 kg | Discrete I/O module | Spring terminal block | 1500 Vrms for 1 min (by photocoupler) | CSA; UL |
| TWDDDO8UT | 0.085 kg | Discrete output module | Removable screw terminal block | 1500 Vrms for 1 min (by photocoupler) | UL; CSA |
| TWDDDO8TT | 0.085 kg | Discrete output module | Removable screw terminal block | 1500 Vrms for 1 min (by photocoupler) | UL; CSA |
| TWDDDO32UK | 0.105 kg | Discrete output module | HE-10 connector | 1500 Vrms for 1 min (by photocoupler) | CSA; UL |
| TWDDDO32TK | 0.105 kg | Discrete output module | HE-10 connector | 1500 Vrms for 1 min (by photocoupler) | UL; CSA |
| TWDDDO16UK | 0.07 kg | Discrete output module | HE-10 connector | 1500 Vrms for 1 min (by photocoupler) | UL; CSA |
| TWDDDO16TK | 0.07 kg | Discrete output module | HE-10 connector | 1500 Vrms for 1 min (by photocoupler) | UL; CSA |
| TWDDDI8DT | 0.085 kg | Discrete input module | Removable screw terminal block | 1500 Vrms for 1 min (by photocoupler) | UL; CSA |
| TWDDDI32DK | 0.1 kg | Discrete input module | HE-10 connector | 1500 Vrms for 1 min (by photocoupler) | CSA; UL |
| TWDDDI16DT | 0.1 kg | Discrete input module | Removable screw terminal block | 1500 Vrms for 1 min (by photocoupler) | CSA; UL |
| TWDDDI16DK | 0.065 kg | Discrete input module | HE-10 connector | 1500 Vrms for 1 min (by photocoupler) | CSA; UL |
| TWDBTFU10M | — | — | — | — | — |
| TWDAMI8HT | 0.085 kg | Analogue input module | Removable screw terminal block | Photocoupler | CSA; UL |
| TWDAMM6HT | — | Analogue I/O module | Removable screw terminal block | Photocoupler | UL; CSA |
Common to all listed parts
| Range of product | Twido |
