RHB2 Motor Hybrid Cables Parts
























Compare RHB2 Motor Hybrid Cables
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Compatible Motors | Connection type of motor connector | Motor-Drive-Connection | cable length [m] | Weight [kg] |
|---|---|---|---|---|---|
| R914510265 | MS2x with plug H | M17 hybrid connector | extension cable | 6.0 | 0 |
| R914510202 | MS2x with plug H | M17 hybrid connector | extension cable | 5.5 | 1.2 |
| R914509988 | MS2x with plug H | M17 hybrid connector | extension cable | 5.0 | 1.1 |
| R914510201 | MS2x with plug H | M17 hybrid connector | extension cable | 4.9 | 1.08 |
| R914510607 | MS2x with plug H | M17 hybrid connector | extension cable | 4.8 | 1.06 |
| R914510200 | MS2x with plug H | M17 hybrid connector | extension cable | 4.6 | 0 |
| R914510199 | MS2x with plug H | M17 hybrid connector | extension cable | 4.0 | 1.52 |
| R914512117 | MS2x with plug H | M17 hybrid connector | extension cable | 3.5 | 0 |
| R914510229 | MS2x with plug H | M17 hybrid connector | extension cable | 3.0 | 0.7 |
| R914510264 | MS2x with plug H | M17 hybrid connector | extension cable | 2.8 | 0.67 |
| R914510198 | MS2x with plug H | M17 hybrid connector | extension cable | 2.6 | 0.64 |
| R914510210 | MS2x with plug H | M17 hybrid connector | extension cable | 2.5 | 0 |
| R914513061 | MS2x with plug H | M17 hybrid connector | extension cable | 2.0 | 0.5 |
| R914513997 | MS2x with plug H | M17 hybrid connector | extension cable | 1.5 | 0 |
| R914509987 | MS2x with plug H | M17 hybrid connector | extension cable | 1.3 | 0.52 |
| R914513909 | MS2x with plug H | M17 hybrid connector | extension cable | 1.0 | 0.33 |
| R914510197 | MS2x with plug H | M17 hybrid connector | extension cable | 0.9 | 0.29 |
| R914515141 | MS2x with plug H | M17 hybrid connector | extension cable | 0.5 | 0 |
| R914518036 | MS2x with plug S | M23 hybrid connector | direct connection | 40.0 | 0 |
| R914518035 | MS2x with plug S | M23 hybrid connector | direct connection | 35.0 | 0 |
| R914505012 | MS2x with plug S | M23 hybrid connector | direct connection | 30.0 | 0 |
| R914505011 | MS2x with plug S | M23 hybrid connector | direct connection | 27.0 | 0 |
| R914504933 | MS2x with plug S | M23 hybrid connector | direct connection | 26.0 | 0 |
| R914509578 | MS2x with plug S | M23 hybrid connector | direct connection | 25.0 | 0 |
Common to all listed parts
| Cable Variant | Hybrid Cable |
| Cable Type | ready-made |
| Compatible Drives | ctrlX DRIVE |
| Cable Model | Basic |
| Dynamic bending radius | 7.5xD |
| Static bending radius | 5xD |
| Bending cycles | 5 million |
| Ambient temperature (storage and transport) [°C] | -40-80 |
