Electrohydraulic steering valves Parts
























Compare Electrohydraulic steering valves
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Electrohydraulic flow, nominal | Circuit type | Integrated priority valve type | Relief valve setting | Software ID |
|---|---|---|---|---|---|
| 83099724 | 20 L/min | Open center | Static, EF bleed | 150-160 Bar | SWID000279 |
| 83099723 | 30 L/min | Load sense dynamic | No Priority valve | 210-220 Bar | SWID000321 |
| 83099657 | 12 L/min | Load sense dynamic | Dynamic | 160-170 Bar | SWID000406 |
| 83099656 | 30 L/min | Steer by Wire | Static | 150-160 Bar | SWID000423 |
| 83099564 | 12 L/min | Open center | Dynamic | 140-150 Bar | SWID000467 |
| 83099526 | 70 L/min | Steer by Wire | Static | 200-210 Bar | SWID000443 |
| 83099480 | 20 L/min | Open center | Dynamic | 160-170 Bar | SWID000042 |
| 83099409 | 30 L/min | Open center | Dynamic | 160-170 Bar | SWID000438 |
| 83099023 | 20 L/min | Open center | Static, EF bleed | 140-150 Bar | SWID000343 |
| 83098875 | 30 L/min | Load sense static | No Priority valve | 210-220 Bar | SWID000358 |
| 83098867 | 20 L/min | Load sense dynamic | No Priority valve | 230-240 Bar | SWID000338 |
| 83097919 | 70 L/min | Load sense dynamic | No Priority valve | 210-220 Bar | SWID000050 |
| 83097536 | 70 L/min | Load sense dynamic | No Priority valve | 210-220 Bar | SWID000072 |
Common to all listed parts
| Product type | EHi |
| P and T front ports | Plastic plugs |
| P and T side ports | Steel plugs |
| CL and CR ports | Plastic plugs |
| Firmware package | Not applicable |
| Cut off connector | Deutsch |
| LS orifice | Regular. 1.2 mm LS orifice |
| Special feature | No special feature |
