Gear motors Parts
Compare Gear motors
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Displacement | Drive gear | Inlet size | Outlet size |
|---|---|---|---|---|
| 121.19.029.00 | Displacement 8,0 cc | Parallel diam. 15 L=30 , Key 4x25 CI01 | 1/2 GAS | 1/2 GAS |
| 121.19.028.00 | Displacement 6,0 cc | Taper 1:8 - M12 x 1,25 - Key = 4 CO01 | 13,5x30xM6 | 13,5x30xM6 |
| 121.19.027.00 | Displacement 11 cc | Taper 1:5 - M12 x 1,25 - Key = 3 CO02 | 15x35xM6 | 15x35xM6 |
| 121.19.026.00 | Displacement 8,0 cc | Spline DIN 5482 B17 x 14 L=10 SC01 | 13,5x30xM6 | 13,5x30xM6 |
| 121.19.025.00 | Displacement 22 cc | Taper 1:8 - M12 x 1,25 - Key = 4 CO01 | 20x40xM8 | 20x40xM8 |
| 121.19.023.00 | Displacement 19 cc | Taper 1:8 - M12 x 1,25 - Key = 4 CO01 | 20x40xM8 | 20x40xM8 |
| 121.19.022.00 | Displacement 14 cc | Taper 1:8 - M12 x 1,25 - Key = 4 CO01 | 20x40xM8 | 20x40xM8 |
| 121.19.021.00 | Displacement 11 cc | Taper 1:8 - M12 x 1,25 - Key = 4 CO01 | 13,5x30xM6 | 13,5x30xM6 |
| 121.19.020.00 | Displacement 25 cc | Parallel diam. 15 L=30 , Key 4x25 CI01 | 23,5x40xM8 | 23,5x40xM8 |
| 121.19.019.00 | Displacement 17 cc | Parallel diam. 15 L=30 , Key 4x25 CI01 | 20x40xM8 | 20x40xM8 |
| 121.19.018.00 | Displacement 14 cc | Parallel diam. 15 L=30 , Key 4x25 CI01 | 20x40xM8 | 20x40xM8 |
| 121.19.017.00 | Displacement 11 cc | Parallel diam. 15 L=30 , Key 4x25 CI01 | 13,5x30xM6 | 13,5x30xM6 |
| 121.19.016.00 | Displacement 8,0 cc | Parallel diam. 15 L=30 , Key 4x25 CI01 | 13,5x30xM6 | 13,5x30xM6 |
| 121.19.015.00 | Displacement 25 cc | Taper 1:8 - M12 x 1,25 - Key = 4 CO01 | 23,5x40xM8 | 23,5x40xM8 |
Common to all listed parts
| D_SIZE GROUP2 | 2 |
| E_VALVE GROUP2 | Without Valve |
| F_DRAIN GROUP2 | Standard |
| Mark position | Position Marking standard (on the top in relation to drive gear) |
| Mark type | Standard Marking |
| O-Ring, Inside Diameter | Slash |
| Ports position | Standard from catalogue |
| Project version | Standard Version of Project |
