Gear motors Parts
Compare Gear motors
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Displacement | Inlet size | Outlet size | Project version | Seals |
|---|---|---|---|---|---|
| 11174752 | Displacement 17 cc | 20x40xM8 | 20x40xM8 | Standard Version of Project | Standard seal |
| 11173747 | Displacement 19 cc | 20x40xM6 | 27x55xM8 | Standard Version of Project | With NBR seals + Dust Cover |
| 11173379 | Displacement 6,0 cc | 7/8-14UNF | 7/8-14UNF | Standard Version of Project | Standard seal |
| 11173211 | Displacement 8,0 cc | 15x35xM6 | 20x40xM6 | Standard Version of Project | Standard seal |
| 11172977 | Displacement 22 cc | Without inlet | Without inlet | Generation II | Standard seal |
| 11172802 | — | — | — | — | — |
| 11172701 | Displacement 11 cc | 1/2 GAS | 1/2 GAS | Standard Version of Project | Standard seal |
| 11172695 | Displacement 11 cc | 1/2 GAS | 1/2 GAS | Standard Version of Project | Standard seal |
| 11172435 | — | — | — | — | — |
| 11172422 | Displacement 11 cc | 12x38,1x17,48xM8(=) | 12x38,1x17,48xM8(=) | Standard Version of Project | With VITON seals + Dust Cover (see SGM2) |
| 11172110 | Displacement 8,0 cc | 7/8-14UNF | 7/8-14UNF | Standard Version of Project | With VITON seals + Dust Cover (see SGM2) |
| 11171997 | Displacement 17 cc | 1/2 GAS | 1/2 GAS | Standard Version of Project | Standard seal |
| 11171939 | — | — | — | — | — |
| 11171927 | — | — | — | — | — |
| 11171187 | Displacement 11 cc | Without inlet | Without inlet | Generation II | Standard seal |
| 11171138 | Displacement 6,0 cc | 7/8-14UNF | 7/8-14UNF | Standard with precharge seal on cover | Standard seal |
| 11170904 | Displacement 22 cc | Without inlet | Without inlet | Generation II | Standard seal |
| 11170671 | Displacement 11 cc | 12x38,1x17,48xM8(=) | 12x38,1x17,48xM8(=) | Standard Version of Project | Product with VITON seals (LCG) |
| 11170148 | Displacement 6,0 cc | Without inlet | Without inlet | Generation II | Standard seal |
| 11170077 | Displacement 12 cc | 1/2 GAS | 1/2 GAS | Standard Version of Project | Standard seal |
Common to all listed parts
| O-Ring, Inside Diameter | Slash |
| Proposition 65 | Cancer and Reproductive Harm |
| Slash separator | Slash |
