Danfoss orbital motor quick selector Parts
Compare Danfoss orbital motor quick selector
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Motor size | Geometric displacement [cm3/r [in3/r]] | Mounting flange type | Shaft type | Seal Kit |
|---|---|---|---|---|---|
| 151B2155 | 315 | 314.5 [19.19] | 4 Bolt - Square | Splined | 151B0129 |
| 151B2154 | 800 | 801.8 [48.93] | 4 Bolt - Square | Straight | 151B0129 |
| 151B2153 | 630 | 629.1 [38.39] | 4 Bolt - Square | Straight | 151B0129 |
| 151B2152 | 500 | 499.6 [30.49] | 4 Bolt - Square | Straight | 151B0129 |
| 151B2151 | 400 | 400.9 [24.46] | 4 Bolt - Square | Straight | 151B0129 |
| 151B2150 | 315 | 314.5 [19.19] | 4 Bolt - Square | Straight | 151B0129 |
| 151B2137 | 500 | 499.6 [30.49] | 4 Bolt - Square | Straight | 151B0127 |
| 151B2132 | 630 | 629.1 [38.39] | 4 Bolt - C | Splined | 151B0129 |
| 151B2091 | 500 | 523.6 [31.95] | 4 Bolt - Short | None | 151B0114 |
| 151B2090 | 400 | 410.9 [25.07] | 4 Bolt - Short | None | 151B0114 |
| 151B2089 | 315 | 326.3 [19.91] | 4 Bolt - Short | None | 151B0114 |
| 151B2088 | 250 | 251.8 [15.36] | 4 Bolt - Short | None | 151B0114 |
| 151B2087 | 200 | 201.4 [12.29] | 4 Bolt - Short | None | 151B0114 |
| 151B2085 | 500 | 523.6 [31.95] | 4 Bolt - Wheel | TAPERED | 151B0113 |
| 151B2084 | 400 | 410.9 [25.07] | 4 Bolt - Wheel | TAPERED | 151B0113 |
| 151B2083 | 315 | 326.3 [19.91] | 4 Bolt - Wheel | TAPERED | 151B0113 |
| 151B2082 | 250 | 251.8 [15.36] | 4 Bolt - Wheel | TAPERED | 151B0113 |
| 151B2081 | 200 | 201.4 [12.29] | 4 Bolt - Wheel | TAPERED | 151B0113 |
| 151B2080 | 160 | 161.1 [9.83] | 4 Bolt - Wheel | TAPERED | 151B0113 |
| 151B2079 | 500 | 523.6 [31.95] | 4 Bolt - Wheel | Straight | 151B0113 |
| 151B2067 | 500 | 523.6 [31.95] | 4 Bolt - C | TAPERED | 151B0113 |
| 151B2066 | 400 | 410.9 [25.07] | 4 Bolt - C | TAPERED | 151B0113 |
Common to all listed parts
| Valve system | Disc valve with valve drive |
| Orbital gearwheel set type | Geroler |
| Motor function | Standard |
| Main port style | Sideport - staggered |
| Brake Release Port Dimension | n/a |
| Painted | No |
| Paint information | n/a |
| Special features hardware | Standard |
