Accessories PMC SC6, PMC SI6 Parts
Pilz
8C000183
Pilz
8C000182
Pilz
8C000181
Pilz
8C000180
Pilz
8C000179
Pilz
8C000178
Pilz
8C000177
Pilz
8C000176
Pilz
8C000175
Compare Accessories PMC SC6, PMC SI6
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Product ID (Pilz order number) | Connector type 1 | Cross section data cable K1 | Net weight | Gross weight |
|---|---|---|---|---|---|
| 8C000174 | 8C000174 | 8-pin M8 female connector | (4x1.5+(2x1.00)+(2x0.50)) mm² | 2480 g | 2480 g |
| 8C000168 | 8C000168 | 8-pin M8 female connector | (4x4.0+(2x1.00)+(2x0.75)) mm² | 4530 g | 4530 g |
| 8C000162 | 8C000162 | 8-pin M8 female connector | (4x2.5 + 2x(2x1.00)) mm² | 4020 g | 4020 g |
| 8C000156 | 8C000156 | 8-pin M8 female connector | (4x10.0+(2x1.50)+(2x1.00)) mm² | 8880 g | 8880 g |
| 8C000150 | 8C000150 | 8-pin M8 female connector | (4x4.0+(2x1.00)+(2x0.75)) mm² | 4530 g | 4530 g |
| 8C000144 | 8C000144 | 8-pin M8 female connector | (4x2.5 + 2x(2x1.00)) mm² | 4020 g | 4020 g |
| 8C000138 | 8C000138 | 8-pin M8 female connector | (4x6.0+(2x1.50)+(2x1.00)) mm² | 6300 g | 6300 g |
| 8C000132 | 8C000132 | 9-pin M15 female connector | (3x1.0+(2x0.50)+(2x0.34)) mm² | 1820 g | 1820 g |
| 8C000114 | 8C000114 | P 12-pin M17 female connector | (3x2x0.14 + 2x0.25) mm² | 720 g | 720 g |
| 8C000108 | 8C000108 | P 12-pin M15 female connector | (3x2x0.14 + 2x0.25) mm² | 830 g | 830 g |
Common to all listed parts
| Lifecycle | Discontinued (no longer manufactured by Pilz) |
| Shape of connector type 1 | straight |
| Contact surfaces material 1 | Au |
| Cable material K1 | Cu |
| Material shield surface K1 | Cu tin-plated |
| Material of cable insulation 1 | PUR |
| Trailing capability of cable 1 | yes |
| Bend radius (when laying) K1 | 5 x Ø |
