ACOPOSinverter P66 - 3-phase 200 to 240 V Parts
Available on requestB&R 8I66T200018.00-000 – Base device for ACOPOSinverter P66 and P64newMPN: 8I66T200018.00-000 · B&R
Price on request
Request a quote
Available on requestB&R 8I66T200037.00-000 – Base device for ACOPOSinverter P66 and P64newMPN: 8I66T200037.00-000 · B&R
Price on request
Request a quote
Available on requestB&R 8I66T200055.00-000 – Base device for ACOPOSinverter P66 and P64newMPN: 8I66T200055.00-000 · B&R
Price on request
Request a quote
Available on requestB&R 8I66T200075.00-000 – Base device for ACOPOSinverter P66 and P64newMPN: 8I66T200075.00-000 · B&R
Price on request
Request a quote
Available on requestB&R 8I66T200110.00-000 – Base device for ACOPOSinverter P66 and P64newMPN: 8I66T200110.00-000 · B&R
Price on request
Request a quote
Available on requestB&R 8I66T200150.00-000 – Base device for ACOPOSinverter P66 and P64newMPN: 8I66T200150.00-000 · B&R
Price on request
Request a quote
Available on requestB&R 8I66T200220.00-000 – Base device for ACOPOSinverter P66 and P64newMPN: 8I66T200220.00-000 · B&R
Price on request
Request a quote
Available on requestB&R 8I66T200300.00-000 – Base device for ACOPOSinverter P66 and P64newMPN: 8I66T200300.00-000 · B&R
Price on request
Request a quote
Available on requestB&R 8I66T200400.00-000 – Base device for ACOPOSinverter P66 and P64newMPN: 8I66T200400.00-000 · B&R
Price on request
Request a quote
Available on requestB&R 8I66T200750.00-000 – Base device for ACOPOSinverter P66 and P64newMPN: 8I66T200750.00-000 · B&R
Price on request
Request a quote
Available on requestB&R 8I66T201100.00-000 – Base device for ACOPOSinverter P66 and P64newMPN: 8I66T201100.00-000 · B&R
Price on request
Request a quote
Available on requestB&R 8I66T201500.00-000 – Base device for ACOPOSinverter P66 and P64newMPN: 8I66T201500.00-000 · B&R
Price on request
Request a quote
Available on requestB&R 8I66T200550.00-000 – Base device for ACOPOSinverter P66 and P64newMPN: 8I66T200550.00-000 · B&R
Price on request
Request a quoteCompare ACOPOSinverter P66 - 3-phase 200 to 240 V
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Specified on nameplate | Apparent power (at 240 VAC) | Power dissipation at nominal load and nominal clock frequency | Max. transient current for 60 s " data-placement="top" data-html="true" data-container="body" data-content="The inverter is designed to operate for a maximum of 60 seconds at 150% nominal current."> | Weight |
|---|---|---|---|---|---|
| 8I66T200018.00-000 | 0.18 kW (0.25 HP) | 0.6 kVA | 21 W | 2.3 A | 0.8 kg |
| 8I66T200037.00-000 | 0.37 kW (0.5 HP) | 1.1 kVA | 34 W | 5 A | 0.9 kg |
| 8I66T200055.00-000 | 0.55 kW (0.75 HP) | 1.5 kVA | 40 W | 5.6 A | 1 kg |
| 8I66T200075.00-000 | 0.75 kW (1 HP) | 2 kVA | 49 W | 7.2 A | 1 kg |
| 8I66T200110.00-000 | 1.1 kW (1.5 HP) | 2.7 kVA | 66 W | 10.4 A | 1.4 kg |
| 8I66T200150.00-000 | 1.5 kW (2 HP) | 3.5 kVA | 69 W | 12 A | 1.4 kg |
| 8I66T200220.00-000 | 2.2 kW (3 HP) | 4.7 kVA | 92 W | 16.5 A | 1.4 kg |
| 8I66T200300.00-000 | 3 kW (4 HP) | 6.1 kVA | 109 W | 20.6 A | 2.2 kg |
| 8I66T200400.00-000 | 4 kW (5 HP) | 7.8 kVA | 141 W | 23.6 A | 2.2 kg |
| 8I66T200750.00-000 | 7.5 kW (10 HP) | 15.3 kVA | 324 W | 49.5 A | 3.6 kg |
| 8I66T201100.00-000 | 11 kW (15 HP) | 21.1 kVA | 528 W | 81 A | 6.8 kg |
| 8I66T201500.00-000 | 15 kW (20 HP) | 27.9 kVA | 545 W | 99 A | 6.9 kg |
| 8I66T200550.00-000 | 5.5 kW (7.5 HP) | 11.8 kVA | 261 W | 41.3 A | 3.5 kg |
Common to all listed parts
| Certifications – CE | Yes |
| Certifications – UKCA | Yes |
| Certifications – CRA (Cyber Resilience Act) | In preparation |
| Certifications – UL | cULus E225616; Power conversion equipment |
| Mains input voltage | 3x 200 VAC -15% to 240 VAC +10% |
| Frequency | 50 to 60 Hz ±5% |
| Integrated EMC filter | No |
| With add-on filter – Motor cable length per IEC/EN 61800-3 ; Cat. C1 environment 1 (public power network) | 1 m |
