ACOPOSinverter P66 - 1-phase 200 to 240 V Parts
Available on requestB&R 8I66S200018.00-000 – Base device for ACOPOSinverter P66 and P64newMPN: 8I66S200018.00-000 · B&R
Price on request
Request a quote
Available on requestB&R 8I66S200037.00-000 – Base device for ACOPOSinverter P66 and P64newMPN: 8I66S200037.00-000 · B&R
Price on request
Request a quote
Available on requestB&R 8I66S200055.00-000 – Base device for ACOPOSinverter P66 and P64newMPN: 8I66S200055.00-000 · B&R
Price on request
Request a quote
Available on requestB&R 8I66S200075.00-000 – Base device for ACOPOSinverter P66 and P64newMPN: 8I66S200075.00-000 · B&R
Price on request
Request a quote
Available on requestB&R 8I66S200110.00-000 – Base device for ACOPOSinverter P66 and P64newMPN: 8I66S200110.00-000 · B&R
Price on request
Request a quote
Available on requestB&R 8I66S200150.00-000 – Base device for ACOPOSinverter P66 and P64newMPN: 8I66S200150.00-000 · B&R
Price on request
Request a quote
Available on requestB&R 8I66S200220.00-000 – Base device for ACOPOSinverter P66 and P64newMPN: 8I66S200220.00-000 · B&R
Price on request
Request a quoteCompare ACOPOSinverter P66 - 1-phase 200 to 240 V
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Specified on nameplate | Apparent power (at 240 VAC) | Power dissipation at nominal load and nominal clock frequency | Max. transient current for 60 s " data-placement="top" data-html="true" data-container="body" data-content="The inverter is designed to operate for a maximum of 60 seconds at 150% nominal current."> | Dimensions – Depth |
|---|---|---|---|---|---|
| 8I66S200018.00-000 | 0.18 kW (0.25 HP) | 0.6 kVA | 22 W | 2.3 A | 109 mm |
| 8I66S200037.00-000 | 0.37 kW (0.5 HP) | 1 kVA | 32 W | 5 A | 128 mm |
| 8I66S200055.00-000 | 0.55 kW (0.75 HP) | 1.4 kVA | 42 W | 5.6 A | 143 mm |
| 8I66S200075.00-000 | 0.75 kW (1 HP) | 1.8 kVA | 48 W | 7.2 A | 143 mm |
| 8I66S200110.00-000 | 1.1 kW (1.5 HP) | 2.5 kVA | 66 W | 10.4 A | 158 mm |
| 8I66S200150.00-000 | 1.5 kW (2 HP) | 3.2 kVA | 82 W | 12 A | 158 mm |
| 8I66S200220.00-000 | 2.2 kW (3 HP) | 4.4 kVA | 110 W | 16.5 A | 158 mm |
Common to all listed parts
| Certifications – CE | Yes |
| Certifications – UKCA | Yes |
| Certifications – CRA (Cyber Resilience Act) | In preparation |
| Certifications – UL | cULus E225616; Power conversion equipment |
| Mains input voltage | 1x 200 VAC -15% to 240 VAC +10% |
| Frequency | 50 to 60 Hz ±5% |
| With integrated filter – Motor cable length per IEC/EN 61800-3 ; Cat. C2 environment 1 (public power network) | 10 m |
| With integrated filter – Motor cable length per IEC/EN 61800-3 ; Cat. C3 environment 2 (industrial power system) | 10 m |
